How Webhooks Actually Work: Data Flow, Retries, and Signatures

A webhook is how the internet taps you on the shoulder. Instead of your code polling an external service every few seconds to check for changes, the service calls your URL the moment something happens. Understanding exactly what occurs between “event fires” and “your handler runs” is what separates a webhook integration that works from one that drops events, processes duplicates, or silently accepts forged requests.

This is the complete picture: data flow, delivery mechanics, verification, async processing, idempotency, and debugging.

What is a webhook?

A webhook is an HTTP callback: an HTTP POST request that an external system sends to a URL you provide, triggered by an event on their side. You do not initiate the request. You register a URL, and the provider calls it.

The term “webhook” was coined by Jeff Lindsay in 2007 as “a pattern for augmenting or altering the behavior of a web page or web application with custom callbacks.” In practice today, webhooks are how nearly every SaaS product — Stripe, GitHub, Shopify, Twilio, Slack — notifies your application of events in real time.

The fundamental difference from a REST API: with a REST API, you call them. With a webhook, they call you. For a detailed side-by-side of both patterns, see webhooks vs APIs.

The complete data flow

Here is every step that occurs from the moment an event fires to the moment your handler finishes processing it.

1. Event occurs on the provider side
       ↓
2. Provider queues a webhook delivery
       ↓
3. Provider sends HTTP POST to your endpoint
       ↓
4. Your server receives the request
       ↓
5. You verify the signature
       ↓
6. You return HTTP 200 (fast — within 5-30s)
       ↓
7. You enqueue the payload for async processing
       ↓
8. Background worker processes the event
       ↓
9. (If step 6 failed or timed out) → Provider retries

Steps 6 and 7 happen before step 8. This is the most commonly misunderstood part of webhook architecture. You return 200 before you finish processing — not after.

Webhook anatomy

Every webhook delivery is an HTTP POST with three components: the URL, the headers, and the body.

The URL

You register your endpoint URL with the provider. This URL must be publicly accessible — localhost:3000 does not work in production. Common patterns:

https://yourapp.com/webhooks/stripe
https://yourapp.com/webhooks/github
https://api.yourapp.com/v1/webhooks/shopify

Use a distinct path per provider. This makes routing, logging, and debugging much simpler than a single catch-all endpoint.

The headers

Providers send metadata in HTTP headers. The most important ones:

Always capture the raw body before parsing. HMAC verification runs on the raw bytes, not the parsed JSON. Parsing first and re-serializing will cause verification to fail.

The payload

The body is a JSON object. The structure varies by provider, but most follow one of two patterns:

Fat payload — the full resource is included:

{
  "id": "evt_1OaBcDEfGhIjKlMn",
  "type": "payment_intent.succeeded",
  "created": 1711929600,
  "data": {
    "object": {
      "id": "pi_3OaBcDEfGhIjKlMn1234",
      "amount": 4999,
      "currency": "usd",
      "status": "succeeded",
      "customer": "cus_OaBcDEfGhIjKlMn",
      "metadata": { "order_id": "ord_789" }
    }
  }
}

Slim payload — only the event type and resource ID are included. You call the API for full details:

{
  "id": "evt_1OaBcDEfGhIjKlMn",
  "type": "payment_intent.succeeded",
  "data": {
    "object": { "id": "pi_3OaBcDEfGhIjKlMn1234" }
  }
}

Stripe uses the fat payload pattern by default but recommends fetching the resource via API after verification. GitHub uses slim payloads for most events.

How delivery works

At-least-once delivery

Webhook providers guarantee at-least-once delivery: every event will be delivered to your endpoint at least one time, but possibly more. There is no guarantee of exactly-once delivery.

You will receive duplicates when:

• Your server returned a non-2xx status code on the first attempt
• Your server timed out and the provider retried
• A network issue caused the provider to not receive your 200 response
• The provider had a bug and sent the event twice

This is not a defect. It is the correct behavior for a reliable distributed system. Your job is to handle it gracefully with idempotency (covered below).

Retry schedules

Providers retry failed deliveries on a schedule. The specifics differ, but all use exponential backoff with a maximum retry count:

A delivery is considered failed if your endpoint returns a non-2xx status code, throws a connection error, or does not respond within the timeout window (5–30 seconds depending on provider). For a deep dive on retry patterns, see webhook retry best practices.

Timeout windows

Most providers time out webhook deliveries after 5–30 seconds. Stripe times out at 30 seconds. GitHub times out at 10 seconds. If your handler takes longer than the timeout, the provider considers the delivery failed and schedules a retry — even if your code eventually processes the event successfully.

This is why async processing is not optional. It is the only way to guarantee you respond within the timeout window regardless of how complex the processing is.

Receiving a webhook: the minimal implementation

Here is a minimal Express.js handler that does everything correctly: verifies the signature, returns 200 fast, and queues the work.

import express from 'express';
import crypto from 'crypto';

const app = express();

// CRITICAL: Use express.raw() — not express.json() — for the webhook route.
// HMAC verification requires the raw request bytes.
app.use('/webhooks/stripe', express.raw({ type: 'application/json' }));

app.post('/webhooks/stripe', (req, res) => {
  const signature = req.headers['stripe-signature'];
  const secret = process.env.STRIPE_WEBHOOK_SECRET;

  // Step 1: Verify the signature
  const expectedSig = crypto
    .createHmac('sha256', secret)
    .update(req.body) // raw Buffer, not parsed JSON
    .digest('hex');

  if (!crypto.timingSafeEqual(
    Buffer.from(signature.split(',').find(p => p.startsWith('v1=')).slice(3)),
    Buffer.from(expectedSig)
  )) {
    return res.status(401).send('Invalid signature');
  }

  // Step 2: Parse the payload
  const event = JSON.parse(req.body);

  // Step 3: Return 200 immediately
  res.status(200).json({ received: true });

  // Step 4: Enqueue for async processing (do NOT await)
  queue.add('process-webhook', {
    eventId: event.id,
    type: event.type,
    payload: event,
  });
});

The same logic in Python with Flask:

import hashlib
import hmac
import json
import os
from flask import Flask, request, jsonify

app = Flask(__name__)

@app.route('/webhooks/stripe', methods=['POST'])
def stripe_webhook():
    payload = request.get_data()  # raw bytes
    signature = request.headers.get('Stripe-Signature', '')
    secret = os.environ['STRIPE_WEBHOOK_SECRET'].encode()

    # Verify HMAC signature
    expected = hmac.new(secret, payload, hashlib.sha256).hexdigest()
    received = next(
        (p.split('=', 1)[1] for p in signature.split(',') if p.startswith('v1=')),
        ''
    )

    if not hmac.compare_digest(expected, received):
        return jsonify(error='Invalid signature'), 401

    event = json.loads(payload)

    # Enqueue asynchronously (Celery, RQ, etc.)
    process_webhook.delay(event['id'], event['type'], event)

    # Return 200 immediately
    return jsonify(received=True), 200

Two details that trip up most implementations:

1. express.raw() not express.json() — parsing the JSON first corrupts the raw bytes needed for HMAC verification.
2. crypto.timingSafeEqual() not === — constant-time comparison prevents timing attacks where an attacker could infer the secret by measuring response time differences.

Signature verification in depth

A webhook signature proves the request came from the provider, not a random attacker who discovered your endpoint URL.

The mechanism: the provider computes an HMAC-SHA256 hash of the request body using a shared secret. They send the hash in a header. You recompute the hash on your side using the same secret. If the hashes match, the request is authentic and the body has not been tampered with.

Provider side:
  signature = HMAC-SHA256(secret, raw_body)
  → Sends: POST /webhooks with header X-Signature: sha256={signature}

Your side:
  expected = HMAC-SHA256(your_secret, raw_body)
  valid = timing_safe_compare(received_signature, expected)

Every provider implements this slightly differently:

Stripe’s format includes a timestamp in the signature header. This enables replay attack protection: if the timestamp is more than 5 minutes old, reject the request even if the HMAC is valid. Without this, an attacker who captured a valid webhook could replay it hours later.

For a complete guide to all verification methods and security hardening, see how to secure your webhook endpoints.

Registering a webhook endpoint

You register your webhook URL with the provider — either through their dashboard or via their API.

Via API (Stripe example):

const stripe = require('stripe')(process.env.STRIPE_SECRET_KEY);

const endpoint = await stripe.webhookEndpoints.create({
  url: 'https://yourapp.com/webhooks/stripe',
  enabled_events: [
    'payment_intent.succeeded',
    'payment_intent.payment_failed',
    'customer.subscription.deleted',
    'invoice.payment_failed',
  ],
});

// Save endpoint.secret — this is your STRIPE_WEBHOOK_SECRET
// It is only shown once at creation time
console.log('Webhook secret:', endpoint.secret);

Via GitHub API:

await fetch(`https://api.github.com/repos/{owner}/{repo}/hooks`, {
  method: 'POST',
  headers: {
    'Authorization': `Bearer ${process.env.GITHUB_TOKEN}`,
    'Content-Type': 'application/json',
  },
  body: JSON.stringify({
    name: 'web',
    active: true,
    events: ['push', 'pull_request', 'release'],
    config: {
      url: 'https://yourapp.com/webhooks/github',
      content_type: 'json',
      secret: process.env.GITHUB_WEBHOOK_SECRET,
    },
  }),
});

Key things to save after registration:

• The webhook secret (for HMAC verification) — shown only once on creation
• The endpoint ID (for updating or deleting the registration later)
• The list of subscribed events (so you know what your handler will receive)

Idempotency: handling duplicates correctly

Because delivery is at-least-once, your handler will occasionally process the same webhook event more than once. Idempotency means running the handler twice produces the same result as running it once.

The standard approach: track processed event IDs and skip events you have already handled.

async function processWebhookEvent(eventId, type, payload) {
  // Check if already processed
  const alreadyProcessed = await db.webhookEvents.findOne({
    where: { eventId }
  });

  if (alreadyProcessed) {
    console.log(`Skipping duplicate event: ${eventId}`);
    return; // idempotent — no-op
  }

  // Process the event
  switch (type) {
    case 'payment_intent.succeeded':
      await fulfillOrder(payload.data.object);
      break;
    case 'customer.subscription.deleted':
      await downgradeAccount(payload.data.object.customer);
      break;
  }

  // Mark as processed (atomic upsert prevents race conditions)
  await db.webhookEvents.upsert({
    eventId,
    type,
    processedAt: new Date(),
  });
}

The deduplication store can be any persistent store: a database table, Redis with a TTL, or a queue with deduplication support. Use the event ID from the provider’s payload as the key — it is stable across retries.

For operations that are inherently idempotent (state checks, upserts, idempotency-key API calls), you may not need explicit deduplication. But for side effects with external impact — sending emails, charging payment methods, posting to Slack — always deduplicate.

Async processing in detail

The pattern is: receive fast, process slow.

Your HTTP handler does the minimum necessary to validate the request and return 200. The heavy work — database writes, API calls, email sending — happens in a background worker.

HTTP handler (< 200ms):
  1. Verify signature
  2. Parse payload
  3. Write raw event to queue/database
  4. Return 200

Background worker (no time limit):
  5. Read event from queue
  6. Check idempotency
  7. Execute business logic
  8. Mark event as processed

The right tool for step 3 depends on your stack:

• Node.js: BullMQ, Bee-Queue, or a database-backed queue like pg-boss
• Python: Celery, RQ, or Dramatiq
• Ruby: Sidekiq or GoodJob
• PHP/Laravel: Laravel queues with database, Redis, or SQS driver
• Go: asynq or a simple goroutine with a persistent store

If you do not have a queue, the minimum viable approach is to write the raw event JSON to a database table and have a background process poll that table. This is less efficient but still correct.

Outbound webhooks: sending webhooks yourself

Everything so far has covered receiving inbound webhooks. If you are building a product that sends webhooks to your users’ endpoints, the architecture is mirrored.

You become the provider. Your responsibilities:

• Storing customer endpoint URLs and secrets
• Queuing delivery attempts on a background worker
• Implementing retry logic with exponential backoff
• Signing payloads with HMAC-SHA256
• Surfacing delivery logs to customers
• Respecting their timeout windows

If you need to send webhooks on a schedule — for example, a daily data export POSTed to a customer’s endpoint — that is where a cron-based HTTP scheduler becomes useful. Recuro handles the scheduling, retry logic, and delivery logging for outbound webhook calls so you do not have to build that infrastructure from scratch.

Common webhook patterns by provider

Stripe

Fat payloads. Signature in Stripe-Signature header with timestamp. Fetch the resource via API after verification (do not trust the payload data directly — it could be stale by the time you process it). Use the Stripe SDK’s constructEvent() for verified parsing.

const event = stripe.webhooks.constructEvent(
  req.body,       // raw body Buffer
  req.headers['stripe-signature'],
  process.env.STRIPE_WEBHOOK_SECRET
);
// Throws if invalid — no need to manually verify

GitHub

Event type in X-GitHub-Event header. Signature in X-Hub-Signature-256. Slim payloads — the full commit data, PR diff, etc., are in the payload but you may still need the API for additional context. Different events have completely different payload schemas.

Shopify

HMAC in X-Shopify-Hmac-SHA256 as Base64. Topic (event type) in X-Shopify-Topic. Fat payloads. Requires accepting application/json and application/x-www-form-urlencoded content types depending on version.

Twilio

Uses a proprietary HMAC scheme over the full URL including query parameters. The Twilio helper library handles verification. Payloads are form-encoded, not JSON.

Debugging webhooks

Webhooks are harder to debug than API calls because you cannot trigger them from a terminal. The three standard tools:

Local tunnels

Tools like ngrok, cloudflared, and localtunnel expose your local development server at a public URL. You register this URL with the provider for testing.

# ngrok
ngrok http 3000

# cloudflared (free, no account needed for basic use)
cloudflare tunnel --url http://localhost:3000

For a full comparison of 7 local debugging tools, see how to test webhooks locally.

Provider dashboards

Stripe, GitHub, and most major providers have webhook delivery logs in their dashboards. You can see every delivery attempt, the request headers and body, the response status code, and the response time. You can replay failed deliveries directly from the dashboard during development.

Request logging middleware

In development, log every incoming webhook before verification so you can inspect payloads even when verification fails:

app.use('/webhooks', (req, res, next) => {
  if (process.env.NODE_ENV !== 'production') {
    console.log('Webhook received:', {
      path: req.path,
      headers: req.headers,
      body: req.body?.toString?.(),
    });
  }
  next();
});

Remove or gate this behind an environment check before deploying to production — logging raw webhook bodies can expose sensitive customer data.

Webhooks vs APIs: when to use each

Webhooks and REST APIs are complementary tools, not alternatives. See webhooks vs APIs for the full comparison. The short version:

Most production integrations use both: register webhooks via the API, receive events via webhook, then call the API for full resource details or to perform follow-up actions. For a comparison with polling, see webhooks vs polling.

Schedule your own HTTP requests with Recuro

Webhooks let external systems notify you. If you need to make scheduled HTTP requests — POSTing to an API on a cron schedule, triggering a build pipeline daily, sending a recurring webhook to your own service — Recuro handles the scheduling, retries, and failure alerts without you building any infrastructure. Define a cron expression, point it at a URL, and every execution is logged with status code, response body, and timing. Create a free account and run your first scheduled HTTP request in under a minute.

Related resources

• Webhooks vs APIs: understanding the difference — when to pull vs when to be pushed
• Webhooks vs polling: when to push and when to pull — efficiency analysis with real numbers
• How to secure your webhook endpoints — HMAC verification, replay protection, SSRF prevention
• Webhook retry best practices — exponential backoff, jitter, and dead letter queues
• How to test webhooks locally — 7 tools for local development
• Webhook scheduling: send HTTP requests on a schedule — cron-based outbound HTTP delivery
• What is a webhook? — the fundamentals
• At-least-once delivery — delivery semantics explained
• Idempotency — why processing twice must equal processing once
• Webhook signature — the cryptography behind request verification
• Exponential backoff — how retry delays are calculated
